Technical Details:

  Axes Travel:

• X axis (longitudinal): 3450 mm
• Y axis (transversal): 790 mm
• Z axis (vertical): 400 mm
• A axis (rotation): 0° ÷ 180°

  Positioning Speed:

• X axis: 50 m/min
• Y axis: 50 m/min
• Z axis: 15 m/min
• A axis: 7200 °/min

  Electro spindle:

• S1 Maximum power: 5 kW
• Maximum speed: 20000 rpm
• Cone tool holder: HSK-F50  Tool Magazine
• Tool change: Automatic
• Maximum number of tools: 8
• Maximum diameter of milling blade: 120 mm
• Maximum diameter of tapping tool: M6

  Workpiece Clamping:

• Number of standard clamps: 4
• Automatic clamp positioning through spindle X axis
• Pneumatic LEFT 0 stop Safety Devices and Guards
• Full guard cabin
• Dimensions (LxPxH): 4350x1750x2140 mm
• Weight: 1800 kg
