• The UNITECH range simplifies the adjustment of welding parameters, making the welder's job easier.
• Each function and parameter can be easily managed and configured via a simplified control panel.
• UNITECH machines are primarily designed for Manual MIG mode.
• Synergic programs can be activated and selected from the front panel.
• High Duty Cycle and user-friendly control panel make HELVI UNITECH an ideal replacement for older transformer welding machines.
• Features the innovative "SPEED SPOT" function for perfect spot welding in MIG mode on any material.
• The HELVI UNITECH range complies with the new Eco Design standards.

TECHNICAL DATA

• Input voltage: 3Ph/400V/50-60Hz
  MIG

• Power 60%: 11.5 KVA

• No load output voltage: 45 V

• Amp. min-max: 30 ÷ 320 A

• Duty Cycle 40°: 320A @ 40%
                              270A @ 60%
                              200A @ 100%
  MMA

• Power 60%: 9.9 KVA

• No load output voltage: 69.5 V

• Amp. min-max: 20 ÷ 270 A

• Duty Cycle 40°: 270A @ 45%
                              250A @ 60%
                              180A @ 100%
  TIG

• Power 60%: 8.2 KVA

• No load output voltage: 12 V

• Amp. min-max: 10 ÷ 320 A

• Duty Cycle 40°: 320A @ 40%
                               270A @ 60%
                               200A @ 100%

• Insulation: H

• Protec. Degree: IP23S

• Machine (LxWxH): 250x610x440 mm

• Weight: 28.55 Kg

FEATURES
