HELVI UNISTAR 528 MIG/MAG Welding Machine
20,800.00 AED
/
HELVISKU: MAXI MIG 308
HELVI UNISTAR 528 MIG/MAG Welding Machine
20,800.00 AED
/
- Three-phase industrial MIG welding units on wheels with thyristor voltage control
- Equipped with 4-roll separate wire feed unit
- Includes 5m interconnecting cable, Euro/Binzel connection, pressure regulator, gas hose, earth cable, and clamp
- Features welding current and arc voltage displays
- Suitable for demanding welding workshops
- Reel holder accepts spools from 5 to 15 kg
- Available with air or water cooling system (R.A. = water cooled optional)
Technical Data:
- Input voltage : 3Ph/230-400V/50-60Hz
- Power 60% : 25 KVA
- No load output voltage : 16 ÷ 48 V
- Current range : 70 % 500 A
- Duty Cycle : 500A @ 60%
400A @ 100% - Steel welding wire : 0.8 - 2 mm
- Stainless steel welding wire : 0.8 - 1.6 mm
- Aluminium welding wire : 0.8 - 2 mm
- Insulation class : H
- Protection degree : IP23S
- Weight : 201 kg
Features:
