• Input voltage: 1Ph/400V/50-60Hz

• Power @ 50%: 25 KVA

• Delayed fuses: 45 A

• Min arm projection: 260 mm

• Max arm projection: 500 mm

• Electrode force: 275 daN (6bar)

• Max welding capacity: 3.0 - 3.0 mm

• Ø Arms: 45 mm

• Dimension (LxWxH): 441x852x1260 mm

• Weight: 125 Kg
