Inside Size

3450*3450*2700mm (L*W*H)

Outside Size

4306*3556*2750mm (L*W*H)

Service Door

One leaf door size: 800*2000mm; Aluminum alloy frame, tempered glass observation, with emergency lock

Wall Panel

Double panels δ =0.426mm with 50mm EPS insulation, front equip one glass observation, size 600 × 600(W× H), right side one panel open one intake with primary filter

Ceiling Board

Double panels δ=0.426mm with 50mm rockwool insulation

Illumination

Ceiling light: 2sets*4pcs=8pcs 18w LED light

Ventilation Unit

One set T30-4C-0.75KW outlet axial flow fan, motor outside, air capacity: 4500m³/h
On the roof panel, equipped exhaust duct 4m straight and one elbow

Filter System

The primary filter in the panels, also have glass fiber filter

Control System

Working Switch, Light switch, fan switch.

Voltage Frequency

3Ph/380V/50Hz

Total Power

0.8 kW
