• Inside Size(LxWxH): 6400×4000×2650mm
• Outside Size(LxWxH): 7603×4000×3400
• Total Power: 9kW

Cabin System

• Roof air plenum construction: Cold rolling bending sprayed plate; Roof Panel: Galvanized steel, Installation type: steel rope hoisting or stanchion.

• Front and Two Sides: electrical PVC curtain.

• 50mm EPS steel skin panel at the back wall, steel sheet thickness: 0.426mm.

• Basement: 300mm height, galvanized steel sheet and square steel pipe assembling,
  two rows of grid & three rows of embossed plate, two embossed steel ramps

Air Circulation System

• The air is exhausted through the back.

• Air inlet: 1*4kw centrifugal fan Model: YDW-4.5AL1; Capacity: 12000m3/h; Pressure: 800Pa; Speed: 900rpm, 1 set, power: 4kw.

• Air exhaust: 1*5.5kw centrifugal fan Model: YDW-4.5AL1; Capacity: 12000m3/h; Pressure: 800Pa; Speed: 900rpm, 1 set, power: 4kw.

• Fan Cabin: Section steel framework, assembly of coated steel plate cabin; Construction: Solid, beautiful and easy for maintenance.

Air Purification System

• The primary filter can capture granules larger than 15μm. Ceiling filter can capture
  granules bigger than 4μm, air pressure balance gauge, TSP≤1.4mg/m3

Environmental System

• The glass fiber filter fixed into outlet fan cabin to reduce the fog, providing a good
  working environment.

Lighting System

• Ceiling Light: 6 sets x 4pcs=24pcs 16W LED Lamp

Electric Control System

• Switched control pane. It is assembled by good electronic components. Main
  circuit is equipped with multiple protection. Working Switch, Light Switch,
  Emergency Stop, Breakdown Alarm.
