ATF 2
Compact point-of-use and lower-flow production duties.
- Motor
- 2 hp
- FAD @ 7 bar
- 186 L/min
- Max pressure
- 10 bar
ABAC Tech · Industrial oil-free piston air
Oil Free.Clean air. Nothing added.
Protect contamination-sensitive processes with an oil-free industrial piston compressor built for reliable, continuous operation.
2–10 HPIndustrial range
UP TO 10 BARMaximum pressure
S1 · 100%Duty cycle
Oil-free compressionNo oil introduced in the compression chamber
Industrial constructionBuilt for daily production demand
Local selectionSized and supported in the UAE by Arwani
The air-quality decision
When air touches the process, compressor oil becomes a business risk.
In food, pharmaceutical, medical and precision production, compressed air can interact with products, packaging and equipment. ATF avoids introducing oil at the compression stage, helping protect downstream equipment and sensitive output.
Compare compressor technologies ↓01
Product contamination
Oil carried into process air can compromise sensitive materials, surfaces or packaging.
02
Downstream damage
Clean air helps protect valves, instruments and production equipment from compressor-oil exposure.
03
Consumable burden
Oil-free compression removes compressor-oil changes from the routine service plan.
04
Wrong-size downtime
Pressure alone is not enough; airflow, duty pattern and treatment must be selected together.
When ATF is the right fit
Specify oil-free air because the process requires it—not because it sounds better.
✓Compressed air can contact the product, ingredients or primary packaging
✓Your process cannot accept contamination introduced by compressor lubrication
✓The compressor must support long daily operating periods or continuous demand
✓You need 2–10 hp and up to 10 bar in a compact industrial piston platform
✓You want power-pack, base, receiver or full-feature installation flexibility
✓You need local sizing, installation guidance, maintenance and parts support
ABAC Tech ATF range
Five sizes. One oil-free industrial platform.
Compare rated free-air delivery at 7 bar. Final selection must allow for simultaneous demand, pressure loss, duty pattern and future capacity.
ATF 3
Growing production cells and multiple small pneumatic users.
- Motor
- 3 hp
- FAD @ 7 bar
- 240 L/min
- Max pressure
- 10 bar
ATF 5.5
Mid-range industrial demand and OEM integration.
- Motor
- 5.5 hp
- FAD @ 7 bar
- 492 L/min
- Max pressure
- 10 bar
ATF 7.5
Higher-flow production and plant-room installations.
- Motor
- 7.5 hp
- FAD @ 7 bar
- 660 L/min
- Max pressure
- 10 bar
Range flagship
ATF 10
The highest airflow in the ATF range, including full-feature options.
- Motor
- 10 hp
- FAD @ 7 bar
- 930 L/min
- Max pressure
- 10 bar
Performance figures from the supplied ABAC Tech leaflet. Unit performance is measured according to ISO 1217, Annex C, latest edition.
Choose the installation
The same decision, packaged four ways.
01
Power pack
Compact compressor assembly for OEM machinery and engineered integrations.
02
Base mounted
Connect to an existing receiver and correctly sized air-treatment system.
03
Receiver mounted
An integrated package for sites that need local compressed-air storage.
04
Full feature
Receiver-mounted package with integrated dryer for a more complete installation.
Priority UAE applications
For processes where clean air protects the output.
The engineering question is not only “how much air?” It is also where the air goes and what it can touch.
F&B
Food & beverage
Packaging, conveying, filling and production tasks where contamination risk matters.
PH
Pharmaceutical
Product movement, coating, mixing-tank pressure and packaging processes.
MD
Medical & dental
Clean, compact compressed air for CAD/CAM laboratories and precision equipment.
PM
Precision manufacturing
Pneumatic controls, presses and product-contact processes across clean production.
OE
OEM integration
Power-pack and base-mounted formats for specialist machinery and engineered systems.
PK
Packaging lines
Oil-free air for actuators, conveyors, sprayers and tightly controlled end products.
Technology comparison
Oil-free and oil-lubricated are different risk decisions.
Both can be valid piston technologies. Choose according to air-quality requirements and operating profile.
General workshop air
Oil-lubricated piston
Oil used inside the compression system
- Suitable where a small oil-contamination risk is acceptable
- Often a lower initial equipment cost
- Requires compressor oil and oil-related service
- Common for tools, workshops and general-purpose air
Choose when process air purity is not critical
Contamination-sensitive air
ABAC ATF oil-free
No oil introduced in the compression chamber
- Designed for clean industrial compressed-air applications
- S1 100% duty cycle across the listed ATF range
- Nickel-plated aluminium cylinders and Teflon-coated pistons
- Power-pack, base, receiver and dryer-equipped configurations
Choose when contamination risk must be designed out
“Oil-free” describes the compressor’s compression process. Required filtration, drying and air-quality verification still depend on your application and site standard.
A better selection conversation
Request technical sizing →
Start with the process—not an assumed horsepower.
Correct sizing protects pressure, compressor life and production continuity. Arwani will translate your operating conditions into an ATF model and installation format.
- 01
Define air quality
Where does the air go, and can it contact products, ingredients or packaging?
- 02
Measure demand
List connected equipment, simultaneous use, required flow and minimum pressure.
- 03
Map the duty
Record hours per day, shifts, load pattern, ambient conditions and expansion plans.
- 04
Complete the air system
Select the receiver, dryer, filtration, piping and installation arrangement together.
UAELocal technical selection
↗Installation guidance
⚙Service & genuine parts
✓Application-led sizing
Qualified ATF enquiry
Tell us what the air must protect.
Share the process, demand and operating pattern. Arwani will recommend the appropriate ATF size, format and downstream treatment.
- ✓Technical review before quotation
- ✓Model and installation recommendation
- ✓UAE after-sales support
